Product Details

• Brand: TOTAL
• Model: TMT5110004
• Product Type: Smart Digital Multimeter
• Display: VA colour display
• Display Resolution: True RMS, 9999 counts
• Measurement Functions: AC/DC voltage, current, resistance, capacitance, frequency, and temperature
• Smart Function: AC/DC voltage, resistance, and continuity
• NCV: Non-Contact Voltage detection
• Live Test: Supported
• Diode Test: Supported
• Current Input Identification: Automatic identification of current input

Measurement Ranges

DC Voltage

• 99.99mV
• 999.9mV
• 9.999V
• 99.9V
• 1000V

AC Voltage

• 99.99mV
• 999.9mV
• 9.999V
• 99.9V
• 750V

Current

• 9.999mA
• 99.99mA
• 600mA
• 10A

Note: The supplied specifications list AC/DC current measurement but explicitly label the current ranges as DC. Confirm AC current capability and applicable ranges with the manufacturer before advertising them.

Resistance

• 999.9Ω
• 9.999kΩ
• 99.99kΩ
• 999.9kΩ
• 9.999MΩ
• 99.99MΩ

Capacitance

• 9.999nF
• 99.99nF
• 9.999µF
• 99.99µF
• 999.9µF
• 9.999mF
• 99.99mF

Frequency

• 99.99Hz
• 999.9Hz
• 9.999kHz
• 99.99kHz
• 999.9kHz
• 9.999MHz

Temperature

• Celsius: -40.0°C to 1000.0°C
• Fahrenheit: -40.0°F to 1832.0°F

Key Features

• VA Colour Display: Provides a clear, colour measurement interface.
• True RMS Technology: Supports True RMS measurements for suitable electrical signals.
• 9999-Count Resolution: Offers detailed digital readings.
• Smart Measurement Function: Supports automatic measurement identification for AC/DC voltage, resistance, and continuity.
• AC/DC Voltage Testing: Measures voltage across multiple ranges.
• Current Measurement: Supports the listed current ranges up to 10A.
• Resistance Testing: Measures resistance up to 99.99MΩ.
• Capacitance Measurement: Tests capacitors across multiple ranges.
• Frequency Measurement: Measures frequency up to 9.999MHz.
• Temperature Measurement: Supports measurements from -40°C to 1000°C.
• NCV Detection: Helps detect the presence of voltage without direct electrical contact.
• Live Test: Includes a live-wire testing function.
• Automatic Current Input Identification: Helps identify the current measurement input.
• Diode Testing: Supports diode checks for electronic troubleshooting.

Suitable For

• Electrical troubleshooting and maintenance
• Electronics testing and repair
• Voltage and current measurements
• Resistance and continuity checks
• Capacitor and frequency testing
• Temperature measurement in supported applications
• Electricians, electronics technicians, and maintenance professionals

Package Contents

Package contents and battery specifications were not included in the supplied product details. Please confirm the included test leads, temperature probe, batteries, and accessories with the seller before listing them.

Important Safety Notes

• Follow the manufacturer's instructions and safety ratings.
• Never exceed the meter's specified measurement limits.
• Select the correct input terminal and measurement mode before testing.
• Confirm the correct current input and range before measuring current.
• Do not connect the meter across a voltage source while configured for current measurement.
• NCV and live-test functions should not replace appropriate electrical safety procedures.
• Use suitable personal protective equipment when testing electrical circuits.
